Yamaha EC-03 2011 1CB3 EUROPE 1K1CB-300E1 13 stand & footrest

With a quantity of four pieces, the Bolt, Flange (25g) is the most used part in the 13 STAND & FOOTREST diagram. The sub assemblies and components that make up this 13 Stand & Footrest include this Stand, Main, the most expensive part. Of all the components that make up this 13 Stand & Footrest the Bolt, Flange (25g) has the lowest price.


1CB2711100 STAND, MAIN 1CB2711400 STOPPER, MAIN STAND 9024010137 PIN, CLEVIS(3KJ) 9290210600 WASHER, PLAIN (7F7) 9140130020 PIN, COTTER 9050635008 SPRING, TENSION 9050623021 SPRING, TENSION 3D22725400 HOOK 5UY2741100 FOOTREST 1 5UY2741300 COVER, FOOTREST 5UY2741300 COVER, FOOTREST 9582208016 BOLT, FLANGE (25G) 9582208016 BOLT, FLANGE (25G) 5UY8257V00 PLATE, CONNECTOR 1CB8252H00 PLATE, HOLDER 9580206010 BOLT, FLANGE (732) 5UY8144400 CLAMP, LEAD 2
view large image
Ref
product
price
Quantity

1
STAND, MAIN
product number: 1CB2711100

€ 232.50

2
STOPPER, MAIN STAND
product number: 1CB2711400

€ 1.50

3
PIN, CLEVIS(3KJ)
PIN, CLEVIS(3KJ)
product number: 9024010137

show photo

€ 6.50

4
WASHER, PLAIN (7F7)
product number: 9290210600
supersession: 9299010600

€ 2.00

5
PIN, COTTER
product number: 9140130020
supersession: 9149030020

€ 2.00

6
SPRING, TENSION
product number: 9050635008

€ 30.00

7
SPRING, TENSION
product number: 9050623021

€ 23.00

8
HOOK
product number: 3D22725400
supersession: 5BM2725410

€ 7.50

9
FOOTREST 1
product number: 5UY2741100

€ 65.00

10
COVER, FOOTREST
product number: 5UY2741300

€ 16.50

11
BOLT, FLANGE (25G)
product number: 9582208016
supersession: 9581108016

€ 0.50

12
PLATE, CONNECTOR
product number: 5UY8257V00

€ 4.00

13
PLATE, HOLDER
product number: 1CB8252H00

€ 12.00

14
BOLT, FLANGE (732)
product number: 9580206010
supersession: 9580106010

€ 0.50

15
CLAMP, LEAD 2
product number: 5UY8144400

€ 1.00
